Renesas RL78/G15是一款功能强大的通用微控制器，适用于各种小型应用场景。以下是其主要特性：
- CPU内核：采用RL78内核，最高运行频率为16MHz，提供高效的处理性能。
- 工作电压：支持范围从2.4V到5.5V，使其能够适应不同的电源供应条件。
- 封装：提供了从8引脚到20引脚的多种封装选项，以满足不同应用的需求。
- 闪存：具有4KB或8KB的程序闪存，以及1KB的SRAM和1KB的数据闪存，提供了足够的存储空间。
- 工作温度：能够在-40°C到125°C的广泛工作温度范围内稳定运行，适用于各种环境条件。
- 定时器：具备8路16位定时器、1路看门狗定时器和1路12位间隔定时器，满足不同的定时需求。
- 模拟功能：包括11路10位A/D转换器和比较器，用于实现模拟信号的处理和比较功能。
- 片上振荡器：内置高精度高速片上振荡器，频率范围从1MHz到16MHz，以及低速振荡器，频率为15kHz。
- 连接接口：支持SCI(包括CSI、UART和简单版I2C)和I2C接口，便于与其他设备进行通信。
- 其他特性：可选的通电重置、低电压检测功能，以及支持片上调试功能，操作电压范围为2.4V到5.5V。
